    90kg 100 Degrees 5kPa Hydrogen Analyzer With 5min Testing Time

    Ask Lasest Price
    Brand Name : HYDEB
    Model Number : CQY-011A
    Certification : ISO CE
    Price : >3000USD/set
    Delivery Time : 50-60 days
    Payment Terms : 30%+70%
    Supply Ability : 500 sets per year
    • Product Details
    • Company Profile

    90kg 100 Degrees 5kPa Hydrogen Analyzer With 5min Testing Time

    Product Description:

    The Hydrogen Analyzer has a compact and sturdy design that makes it easy to handle and transport. It weighs only 90kg, which makes it highly portable. The vacuum chamber size is Φ90×50, which provides ample space for the sample to be tested. The ultimate vacuum of the vacuum chamber is 5kPa, which ensures that the test results are accurate and reliable. The vacuum chamber allows a maximum temperature of 100℃, which means that the instrument can be used to test molten aluminum at high temperatures.

    The Hydrogen Analyzer is a vacuum gas test instrument that uses advanced technology to accurately measure the hydrogen content in molten aluminum. The measuring time is less than 5 minutes, which means that the instrument can quickly provide accurate results. This makes it a highly efficient tool for any aluminum casting or production process.

    The Hydrogen Analyzer is an essential tool for any aluminum casting or production facility. It is a reliable and accurate instrument that can help to ensure the quality of the final product. With its advanced technology and compact design, it is easy to use and transport. The Hydrogen Analyzer is a must-have tool for anyone involved in the aluminum casting or production process.

    90kg 100 Degrees 5kPa Hydrogen Analyzer With 5min Testing Time

    Features:

    • Product Name: Hydrogen Analyzer
    • Vacuum chamber allows maximum temperature: 100℃
    • Ultimate vacuum of vacuum chamber: 5kPa
    • Overall dimension: 600mm×550mm×950mm
    • Measuring time: <5min
    • Vacuum chamber size: Φ90×50

    Our Hydrogen Analyzer systems come equipped with a vacuum chamber that allows for a maximum temperature of 100℃. With an ultimate vacuum of 5kPa, our vacuum gas test ensures accurate and reliable measurements. The overall dimension of the analyzer is 600mm×550mm×950mm, and measuring time is less than 5 minutes. The vacuum chamber size is Φ90×50.

    Technical Parameters:

    Measuring time<5min
    Vacuum chamber sizeΦ90×50
    Overall dimension600mm×550mm×950mm
    Ultimate vacuum of vacuum chamber5kPa
    Instrument power≤370W
    Power supply220vAC/50Hz
    Time to limit vacuum≤10S
    Instrument weight90kg
    Vacuum chamber allows maximum temperature100℃

    The Hydrogen Analyzer is a qualitative test instrument for detecting hydrogen content in liquid aluminum. It is used for the determination of hydrogen content in molten aluminum and for vacuum gas tests.

    90kg 100 Degrees 5kPa Hydrogen Analyzer With 5min Testing Time

    Applications:

    The HYDEB CQY-011A hydrogen analyzer is a perfect fit for various occasions and scenarios. It can be used in foundries, aluminum processing plants, and research institutions. The instrument is reliable and provides accurate results in less than five minutes, making it an ideal solution for industries where time is of the essence.

    The HYDEB CQY-011A hydrogen analyzer is designed to measure the hydrogen content in molten aluminum using the vacuum coagulation test. The vacuum chamber size is Φ90×50 and can allow a maximum temperature of 100℃. This feature makes the instrument highly efficient and reliable in determining the hydrogen content in molten aluminum.

    The HYDEB CQY-011A hydrogen analyzer system is packaged in a wooden box for safe transportation. The instrument weighs 90kg and has a power supply of 220vAC/50Hz. The instrument is available for purchase for prices starting at >3000USD/set. The delivery time for the instrument is 50-60 days, and the payment terms are 30%+70%. The supply ability of the instrument is 500 sets per year.

    Customization:

    Our Hydrogen Analyzer is certified with ISO CE and has a minimum order quantity of 1. The price of the analyzer is >3000USD/set and the delivery time is 50-60 days. We offer a payment term of 30%+70% and have a supply ability of 500 sets per year.

    For your convenience, we offer customizable options for the analyzer to suit your specific needs. Our customizable options include Vacuum Gas Test and other modifications as per your requirements.

    Support and Services:

    The Hydrogen Analyzer product technical support and services include:

    • Installation support and guidance
    • Product training and education
    • Product troubleshooting and problem solving
    • Product maintenance and repair services
    • Technical documentation and manuals
    • Software updates and upgrades
    • Remote technical support and assistance
    • On-site technical support and assistance

    Packing and Shipping:

    Product Packaging:

    • 1 Hydrogen Analyzer Unit
    • 1 Power Cable
    • 1 User Manual
    • 1 Calibration Certificate

    Shipping:

    • Shipping Method: FedEx Ground
    • Shipping Cost: $50.00
    • Estimated Delivery Time: 3-5 business days
    • Tracking Number: Provided upon shipment

    FAQ:

    Here are some frequently asked questions and answers about HYDEB's CQY-011A Hydrogen Analyzer:

    Q: What is the minimum order quantity for the CQY-011A Hydrogen Analyzer?

    A: The minimum order quantity for the CQY-011A Hydrogen Analyzer is 1.

    Q: What is the price of the CQY-011A Hydrogen Analyzer?

    A: The price of the CQY-011A Hydrogen Analyzer is >3000USD/set.

    Q: Where is the CQY-011A Hydrogen Analyzer manufactured?

    A: The CQY-011A Hydrogen Analyzer is manufactured in Jinan, China.

    Q: What certifications does the CQY-011A Hydrogen Analyzer have?

    A: The CQY-011A Hydrogen Analyzer is certified with ISO CE.

    Q: What is the delivery time for the CQY-011A Hydrogen Analyzer?

    A: The delivery time for the CQY-011A Hydrogen Analyzer is 50-60 days.

    Q: What are the payment terms for the CQY-011A Hydrogen Analyzer?

    A: The payment terms for the CQY-011A Hydrogen Analyzer are 30%+70%.

    Q: What is the supply ability for the CQY-011A Hydrogen Analyzer?

    A: The supply ability for the CQY-011A Hydrogen Analyzer is 500 sets per year.

    Q: How is the CQY-011A Hydrogen Analyzer packaged for shipping?

    A: The CQY-011A Hydrogen Analyzer is packaged in a wooden box for shipping.
