    600 KG Aluminum Melting Furnace

    Ask Lasest Price
    Brand Name : Hydeb
    Model Number : CRL-600
    Certification : CE,ISO9001,ISO14001,IS45001,High-tech Enterprise
    Price : $ 20000-$50000/set
    Payment Terms : T/T
    Supply Ability : 20 sets per year
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    600 KG Aluminum Melting Furnace

    Electricity Power 600KG Blue Aluminum Alloy Smelting Furnace For Alumium Alloy Die Casting


    600KG Capacity Electric Heating Smelting Crucible Furnace


    1. Smelting Furnace Description


    The smelting furnace is used in all foundries or aluminum die casting area. It smeltery for feeding holding furnaces
    or for direct casting.


    The smelting furnace low heat losses through high-quality insulation.


    And there is no exhaust system needed.

    2. Smelting Furnace Mainly Specification


    SNItemsDataRemarks
    1Efficient furnace capacity kg (Al)420Not fixed
    2Melting Rate kg/h (Al)240Inside the crucible there is already have 1/3 molten aluminum.
    5Maximum furnace temperature ℃950
    6Precision of molten aluminum temperature control ℃≤± 5
    7Temperature control modePID+Dual temperature control
    8Crucible type and size mmOD 880, d 350mm, H 1000

    BN800

    Morgen

    9Furnace surface temperature rise ℃≤50Except for the installation site of the heating tube, the discharge outlet and rising tube
    11Power SourceVoltage V380
    Frequency HZ50
    12Air Pressure MPa0.5-0.7

    3. Smelting Furnace Furnace Types


    TypeCRL-300CRL-500CRL-600CRL-800CRL-1000CRL-1200
    Capacity191KG338KG515KG763KG952KG1062KG

    4. Ready For Delivery



    5. Our CE Certification



    6. Company Introduce


    Jinan Hydeb Thermal Tech Co., Ltd was established in January 2003, and now has 56 employees,among which there are
    8 technical engineers.

    The sales in 2020 is 50 million RMB.


    Hydeb focus on one industry -- "aluminum casting".


    Hydeb has a complete product line of aluminum casting equipment, all products are independent research and development,
    manufacturing

    -- aluminum melting and holding, transportation, ladle preheating, aluminum liquid refining, aluminum liquid hydrogen measurement,
    until aluminum solution aging treatment equipments.

    7. FRQ

    Q1: I know nothing about this machine, what kind of machine I should choose?
    Very easy. We will email you an inquiry form for making sure your real need. Or just tell us what you want to
    do by using this machine, then let us give you perfect solutions and suggestions.


    Q2: When I get this machine, but I don’t know how to use it. What should I do?
    We will send pictures or video and English manual with the machine. If you still have some doubts, we can talk
    by Telephone/ Skype / Whatsapp / Weichat/ E-mail.


    Q3: If some problems happen to this machine during warranty period, what should I do?
    We will supply free parts during machine warranty period if machine have some problems (except spare parts).
    While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
